Reverse Tap Dispensers

Different sizes for every use your store many need

The ReverseTap Machines are so fast that one trained bartender can fill up to 12 cups per minute, that is 5 SECONDS PER CUP (depending on cup size) and 4 times faster than conventional dispensing.

ReverseTap Basic Counter-Top with LCD Dual Nozzle

ReverseTap Basic Counter-Top Single Nozzle

ReverseTap Premium In-Counter Dual Nozzle

ReverseTap Basic In-Counter Single Nozzle

ReverseTap Premium Counter-Top w/Backlit Display Dual Nozzle

ReverseTap Premium Counter-Top w/Backlit Display Single Nozzle

Title

ReverseTap Basic Counter-Top with LCD
Dual Nozzle

Info
ModelRD-BL2
Product Size350 x 357 x 140 (mm)
LCD Display Size7 inch LCD Disply
Product Weight7.5 kg
Packaging Size440 x 427 x 214 (mm)
Packaging Weight8.4 kg
Title
Reversetap Twin unit Counter top FEATURES:

Features:
Video contents can be displayed with USB, 7″ LCD, Speaker, Each dispenser can serve different liquids

Components:
Main frame, Plate, Hole covers (2), 2 Set of grippers, Nozzle (2), Adapter, Remote controller, Etc

Waterproof:
Dispensing area (upper part): 100% waterproof; Display area (control part): Water resistant

Maintenance:
After disassembling the nozzle and gripper, rinse the dispense with warm water. (Don’t use the scrubber). Place the lids on top of the dispenser during non-operation.

Video:
Video can be auto-played once USB with video contents is plugged in. (USB slot is located at the bottom left of the front frame)

S/W Upgrade:
S/W version can be upgraded with USB. (USB slot is located at the bottom right of the front frame)

Title

ReverseTap Basic Counter-Top
Single Nozzle

Info
ModelRD-B1
Product Size238 x 300 x 99 (mm)
Product Weight1.5 kg
Packaging Size365 x 330 x 142 (mm)
Packaging Weight3 kg
Title
Reversetap single unit Counter top FEATURES:

Components:
Main frame, Plate, Hole cover, Gripper, Nozzle, Adapter

Waterproof:
Dispensing area (upper part): 100% waterproof; Display area (control part): Water resistant

Maintenance:
After disassembling the nozzle and gripper, rinse the dispense with warm water. (Don’t use the scrubber). Place the lids on top of the dispenser during non-operation.

Title

ReverseTap Premium In-Counter
Dual Nozzle

Info
ModelRD-SF2
Product Size320 x 302 x 100(33) (mm)
Product Weight4.5 Kg
Packaging Size370 x 450 x 150 (mm)
Packaging Weight5.5 kg
ColorFlat Metallic Silver
Title
Reversetap dual premium unit FEATURES:

Components:
Main frame, Plate, Hole cover, Gripper, Nozzle, Adapter, Etc.

Waterproof:
Dispenseing area(upper part) : 100% waterproof; Display area(control part) : Water resistant

Maintenance:
After disassembling the nozzle and gripper, rinse the dispense with warm water. (Don’t use the scrubber). Place the lids on top of the dispenser during non-operation.

Note:
This product is available from 2018 in the following countries and regions: Europe, Oceania, Africa, Middle East, India, Japan, Russia, China, Taiwan, Hong Kong

Title

ReverseTap Basic In-Counter
Single Nozzle

Info
ModelRD-BF1
Product Size208 x 279 x 100 (27) (mm)
Product Weight1.5 kg
Packaging Size365 x 330 x 142 (mm)
Packaging Weight3 kg
Title
Reversetap single in counter unit FEATURES:

Components:
Main frame, Plate, Hole cover, Gripper, Nozzle, Adapter

Waterproof:
Dispensing area (upper part): 100% waterproof; Display area (control part): Water resistant

Maintenance:
After disassembling the nozzle and gripper, rinse the dispense with warm water. (Don’t use the scrubber). Place the lids on top of the dispenser during non-operation.

Title

ReverseTap Premium Counter-Top w/Backlit Display
Dual Nozzle

Info
ModelRD-S2
Product Size384 x 372 x 140 (mm)
Product Weight9.5 kg
Packaging Size430 x 430 x 190 (mm)
Packaging Weight10.5 kg
Title
Reversetap RD-SD2 FEATURES:

Features:
Advertising brands by using 12.4inch front BLU

Components:
Main frame, Plate, Hole cover, Gripper, Nozzle, Adapter

Maintenance:
After disassembling the nozzle and gripper, rinse the dispense with warm water. (Don’t use the scrubber). Place the lids on top of the dispenser during non-operation.

Waterproof:
Dispensing area (upper part): 100% waterproof; Display area (control part): Water resistant

Note:
This product is available from 2018 in the following countries and regions: Europe, Oceania, Africa, Middle East, India, Japan, Russia, China, Taiwan, Hong Kong

Title

ReverseTap Premium Counter-Top w/Backlit Display
Single Nozzle

Info
ModelRD-S1
Product Size248 x 372 x 140 (mm)
Product Weight6.5 kg
Packaging Size294 x 430 x 190 (mm)
Packaging Weight7.5 kg
Title
Reversetap RD-S1 FEATURES:

Features:
7.6inch BLU can be attached

Components:
Main frame, Plate, Hole cover, Gripper, Nozzle, Adapter

Waterproof:
Dispensing area (upper part): 100% waterproof; Display area (control part): Water resistant

Maintenance:
After disassembling the nozzle and gripper, rinse the dispense with warm water. (Don’t use the scrubber). Place the lids on top of the dispenser during non-operation.

Note:
This product is available from 2018 in the following countries and regions: Europe, Oceania, Africa, Middle East, India, Japan, Russia, China, Taiwan, Hong Kong
